Dell PowerEdge MX740C Blade Server CTO Chassis

DELL Poweredge MX740C Blade Server Cto Chassis.

General Information :

Manufaturer : DELL Technologies

Manufaturer Website Address : WWW.DELL.COM

Part Number : MX740C

Type : Server – Blade

Product Name : DELL Poweredge MX740C Blade Server Cto Chassis

Processor / Chipset :

Cpu : Intel Xeon

Number Of Cores : Up To 28-core

Install Cpu Qty : 0

Max Cpu Qty : 2

Cpu Upgradability : Upgradable

Processor Main Features : Intel Quickassist Technology

Chipset Type : Intel C628

Ram :

Installed Size : 0 Gb (installed)

Technology : Ddr4 Rdimms, Lrdimms

Rated Memory Speed : 2933 Mhz

Form Factor : Dimm 288-pin

Slots : 12 (total) / 12 (empty)

Configuration Features : 0 Gb

Maximum Memory Configuration: Rdimm 1.5tb, Lrdimm 3tb, Nvdimm-n 192gb, Dcpmm 6.144tb

Internal Storage Devices :

Hard Drive / Type : Hdd

Hdd : Up To 6x 2.5 Hot-swap Sata/sas Hdds Or Ssds, Or Nvme Pcie Ssd Drives

Installed Qty : 0

Optical Drive : No Optical Drive

Storage Controller :

Internal Controllers : S140 Software Raid, Hba330 Internal Sas Hba, Perc H730p Adapter, Perc H745p Adapter, Hba330 Mini-mezzanine Sas Hba

Internal Boot Options: Choice Of Optional Boot Optimized Storage Solution (boss) (2 X M.2 Sdds) Or Internal Dual Sd Module (idsdm)

Installed Qty : 0

Networking :

Mx7000 Chassis Fabric Options: Up To 2 Pairs Redundant General Purpose Switch Or Pass-through Modular Bays (fabrics A And B)

Redundant Pair Of Storage Specific Switch Bays (fabric C)

Up To 25gbe, 32gbps Fibre Channel, 12gbps Sas

Installed Qty : 0

Management:

Integrated DELL Remote Access Controller (idrac)

DELL Emc Openmanage Enterprise Modular (ome-m)

Idrac Service Module (ism)

Power Supplies :

Mx7000 Chassis: Up To 6x 3000w, Psu And Grid Redundancy Support

Installed Qty : 0

Fans :

Mx7000 Chassis: 5 Rear And 4 Front-accessible Hot-swap Fans

Installed Qty : 0

Front Panel :

Front Ports

1x Usb 3.0 Port External Port

Right Control Panel Ear

Power Button And Led Indicators

2 X Usb Type-a

1 X Usb Type Micro-ab

1 X Mini Displayport

Left Control Panel Ear- 3 Configurations

Lcd With Quicksync

Lcd Without Quicksync

Led Indicators Only

Sleds :

8x Single-width Or 4x Double-width Sleds

Double Wide Sleds In Slots 1-2, 3-4, 5-6, 7-8

Expansion Slots :

Up To 48 Pcie Gen3 Lanes Per Cpu With X16, X8 And X4 Bifurcation Support

Two Pcie 3.0 X16 Mezzanine Slots (fabrics A And B)

One Pcie 3.0 X16 Mini-mezzanine Slot (fabric C)

Dimensions & Weight :

Length : 620.35mm (24.2 Inches)

Width : 250.2mm (9.8 Inches)

Depth : 42.14mm (1.65 Inches)

Weight : 9.5 Kg (20.94 Lbs)

Condition : Refurbished

Availability : In Stock

Our Warranty : 90 Days
