General Information :
Manufacturer : Hewlett Packard Enterprise
Manufacturer Part Number : 736958-001
Manufacturer Website Address : WWW.HPE.COM
Product Name : Proliant Ml350p Gen8 – 2-way 5u Tower Server ( Base Model)
Processor & Chipset :
Processor Type : Intel Xeon E5-2620v2 / 2.1 Ghz
Number Of Cores : 6-core
64-bit Computing : Yes
Installed Qty : 1
Max Supported Qty : 2
Upgradability : Upgradable
Chipset Type : Intel C600
Cache Memory :
Cache Memory Type : L3 Cache
Installed Size : 15 Mb
Cache Per Processor : 15 Mb
Ram :
Installed Size : 8 Gb / 384 Gb (max)
Technology : Ddr3 Sdram
Effective Memory Speed : 1600 Mhz
Rated Memory Speed : 1600 Mhz
Memory Specification Compliance : Pc3-12800
Form Factor : Dimm 240-pin
Slots : 24 (total) / 23 (empty)
Features : Registered, Quad Channel Memory Architecture, Low-voltage, Hp Smartmemory
Configuration Features : 1 X 8 Gb
Ram Supported : Pc3-12800 – 384 Gb Registered Pc3-10600 – 128 Gb Unbuffered – Advanced Ecc
Storage & Optical Storage :
Hard Drive : None
Optical Drive Type : Dvd-rom – Serial Ata
Storage Controller :
Type : 1 X Raid – Integrated – Pcie 3.0 X8
Controller Interface Type : Sata 6gb/s / Sas 6gb/s
Storage Controller Name : Smart Array P420i With 512mb Fbwc
Channel Qty : 8
Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
Buffer Size : 512 Mb
Display & Graphics Controllers :
Type : Integrated
Graphics Processor : Matrox G200
Video Interfaces : Vga
Network & Communication:
Type : Integrated
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller : Hp 331i
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : Ipmi 2.0, Smash Clp
Remote Management Controller : Integrated Lights-out 4
Features : Wake On Lan (wol), Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab
Expansions & Connectivity :
Expansion Bays Total (free) :
3 (total) / 2 (free) X Front Accessible – 5.25in X 1/2h
6 (total) / 6 (free) X Hot-swap – 3.5in Lff
Expansion Slots Total (free):
24 (total) / 23 (free) X Dimm 240-pin
2 (total) / 1 (free) X Cpu
1 (total) / 1 (free) X Pcie 3.0 X16 – Full-length, Full-height (x8 Mode)
4 (total) / 4 (free) X Pcie 3.0 X8 – Full-length, Full-height (x4 Mode)
1 (total) / 1 (free) X Pcie 2.0 X8 – Half-length, Full-height (x4 Mode)
3 (total) / 3 (free) X Pcie 3.0 X16 – Full-length, Full-height
1 (total) / 1 (free) X Sd Card (internal)
Interfaces & Ports :
1 X Serial
1 X Vga
4 X Lan (gigabit Ethernet)
1 X Hp Ilo
8 X Usb 2.0 ( 4 Front, 4 Rear )
Miscellaneous :
Features :
Administrator Password
Power-on Password
Serial Port I/o Control
Compliant Standards :
Acpi 2.0b, En 61000-3-2, En55022, Ices-003, En 61000-3-3, En55024, Cispr 22, Iec 60950-1, En 60950-1, Bsmi Cns 13438, Fcc Cfr47 Part 15 B
Power Device :
Device Type : Power Supply – Hot-plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (with Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Voltage Required : Ac 120/230 V ( 50/60 Hz )
Power Provided : 460 Watt
80 Plus Certification : 80 Plus Gold
Dimensions & Weight :
Width : 8.6 In
Depth : 29.1 In
Height : 18.2 In
Weight : 70.33 Lbs
Condition : Refurbished
Availability : In Stock
Our Warranty : 90 Days
