General Information :
Manufacturer : Hewlett Packard Enterprise
Manufacturer Part Number : 742657-B21
Manufacturer Website Address : WWW.HPE.COM
Product Name: Proliant Dl560 Gen9 – 2u Rack Mountable Server ( Cto Model)
Processor & Chipset :
Cpu : No Cpu
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Chipset Type : Intel C610 Series
Memory :
Installed Size : 0 Gb / 1.5 Tb (max)
Technology : Ddr4 Sdram
Form Factor : Dimm 288-pin
Slots : 24 (total) / 24 (empty)
Ram Supported : Pc4-17000 – 1.5 Tb Registered Pc4-17000 – 1.5 Tb Load-reduced
Storage:
Hard Drive : None
Optical Drive : None
Storage Controllers:
Type : 1 X Raid
Controller Interface Type : Sata 6gb/s / Sas 6gb/s
Storage Controller Name : Hp Dynamic Smart Array B140i
Raid Level : Raid 0, Raid 1, Raid 5, Raid 10
Display & Graphics Controllers :
Graphics Processor : Matrox G200
Video Interfaces : Vga
Expansion/ Connectivity :
Expansion Bays Total (free) :
8 (total) / 8 (free) X Hot-swap 2.5 Sff
Expansion Slots Total (free) :
1 (total) / 1 (free) X Flexiblelom
24 (total) / 24 (free) X Dimm 288-pin
4 (total) / 4 (free) X Cpu
2 (total) / 2 (free) X Pcie 3.0 X16 – Half-length, Full-height (x8 Mode)
1 (total) / 0 (free) X Pcie 3.0 X8 – Half-length, Full-height
2 (total) / 2 (free) X Pcie 3.0 X16 – Half-length, Full-height (x8 Mode, 2 Processors Must Be Installed)
2 (total) / 2 (free) X Microsd Card
1 (total) / 1 (free) X Pcie 3.0 X8 – Half-length, Full-height (2 Processors Must Be Installed)
1 (total) / 1 (free) X Pcie 3.0 X16 – Half-length, Full-height (2 Processors Must Be Installed)
Interfaces & Ports :
1 X Serial
1 X Vga
1 X Hp Ilo
3 X Usb 2.0 (2 Rear, 1 Internal)
4 X Usb 3.0 (1 Front, 2 Rear, 1 Internal)
Miscellaneous :
Features :
Administrator Password
Power-on Password
Serial Port I/o Control
80 Plus Platinum Plus
Compliant Standards :
Acpi 2.0, Fcc Class A Certified, En 61000-3-2, En55022, Ices-003, En 61000-3-3, En55024, Cispr 22, Fcc Cfr47 Part 15, Iec 60950-1, En 60950-1, Weee, Gb 9254, Ashrae, Cns 13438
Manufacturer Selling Program :
Cto
Dimensions & Weight :
Width : 17.5 In
Depth : 29.5 In
Height : 3.4 In
Weight : 39 Lbs
Availability : In Stock
Condition : Refurbished
Our Warranty : 90 Days
