General Information :
Manufacturer : Hewlett Packard Enterprise
Manufacturer Part Number : 779805-S01
Manufacturer Website Address : WWW.HPE.COM
Product Name: Proliant Dl360 Gen9 – Blade Server ( S-buy)
Processor & Chipset :
Processor Type : Intel Xeon E5-2640v3/ 2.6ghz
Max Turbo Speed : 3.4 Ghz
Quickpath Interconnect: 9.60 Gt/s
Number Of Cores : 8-core
64-bit Computing : Yes
Compatible Processor Socket : Fclga2011-3
Installed Qty : 2
Max Supported Qty : 2
Chipset Type : Intel C610 Series
Cache Memory :
Installed Size : L3 Cache – 40 Mb
Cache Per Processor : 20 Mb
Ram :
Installed Size : 64 Gb / 512 Gb (max)
Technology : Ddr4 Sdram – Advanced Ecc
Effective Memory Speed : 1866 Mhz
Rated Memory Speed : 2133 Mhz
Memory Specification Compliance : Pc4-17000
Form Factor : Dimm 288-pin
Slots : 16 (total) / 12 (empty)
Features : Registered, Online Spare Memory, Hp Smartmemory
Configuration Features : 4 X 16 Gb
Ram Supported : 512 Gb Registered – Advanced Ecc 2 Tb Load-reduced – Advanced Ecc
Storage:
Hard Drive : None
Optical Drive : None
Storage Controllers:
Storage Controller Name : Smart Array H244br
Buffer Size : None
Disk Drive : 12gb/ssas (serial Attached Scsi)
Protocol Support : 6gb/s Sata (serial Advanced Technology Attachment)
Data Transfer Method : 12gb/s Per Port For Combined Throughput Of Up To 24gb/s
Pcie Bus Speed : Pcie 3.0 X8 (8gt/s Maximum Bandwidth)
Port Transfer Rate : 24gb/s Per X1 Sas Port (2x 12gb/s)
Maximum Capacity : 2.4tb Sas,2.4tb Sata
Memory Addressing : 64-bit, Supporting Servers Memory Greater Than 4gb
Raid Support : Raid 0, Raid 1, Raid 10
Display & Graphics:
Graphics Controller Type : Integrated Matrox G200eh
Network & Communication:
Ethernet Controller : Hp Ethernet 10gb 2-port 536flb Adapter
Network Processor : Qlogic 57840s With Integrated Mac/phy
Data Rate : Two Ports, Each At 20 Gbps Full Duplex, 40 Gbps Aggregate Full Duplex Theoretical Bandwidth
On-board Buffer Memory : 900mb (distributed Memory)
Bus Type : Pci Express V3.0 (gen 3) X8
Form Factor : Flexiblelom
Ieee Compliance : 802.3, 802.1ab, 802.3x, 802.3ad, 802.3p, 802.1q, 802.3ae, 802.1qau, 802.3ap
Expansion/ Connectivity :
Expansion Bays Total (free) :
2 (total) / 2 (free) X Hot-swap 2.5 Sff
Expansion Slots Total (free) :
2 (total) / 0 (free) X Cpu
16 (total) / 12 (free) X Dimm 288-pin
2 Expansion Slot (x16 Mode)
1 (total) / 1 (free) X Micro-sdhc Card (internal)
1 (total) / 0 (free) X Flexiblelom
Interfaces & Ports :
1 X Hp Ilo
1 X Usb 3.0 (1 Internal)
2 X Lan (10gigabit Ethernet)
Miscellaneous :
Features :
Administrator Password
Power-on Password
Keyboard Password
Usb Port Control
Quicklock
Compliant Standards :
Acpi 2.0, Fips 140-2 Level 2, Aes, Triple Des, Ashrae
Manufacturer Selling Program :
Hp Smart Buy
Dimensions & Weight:
Width : 2.2 In
Depth : 20.4 In
Height : 7.1 In
Weight : 10.5 Lbs
Condition : Refurbished
Availability : In Stock
Our Warranty : 90 Days
