General Information :
Manufacturer : Hewlett Packard Enterprise
Manufacturer Part Number : 877619-001
Manufacturer Website Address : WWW.HPE.COM
Product Name : Proliant Ml350 Gen10 – 4u Tower Server ( Sub-entry Model)
Processor & Chipset :
Cpu : 1st Gen Intel Xeon Bronze 3204 / 1.9 Ghz
Number Of Cores : 6-core
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Processor Main Features : Hyper-threading Technology
Cpu Socket : Fclga3647 Socket
Chipset Type : Intel C622
Cache Memory :
Installed Size : L3 Cache – 8.25 Mb
Cache Per Processor : 8.25 Mb
Memory :
Installed Size : 8 Gb / 768 Gb (max)
Technology : Ddr4 Sdram – Advanced Ecc
Effective Memory Speed : 2133 Mhz
Rated Memory Speed : 2666 Mhz
Memory Specification Compliance : Pc4-20800
Form Factor : Dimm 288-pin
Slots : 24 (total) / 23 (empty)
Features : Registered, Online Spare Memory, HPE Smartmemory, 6-channel Memory Architecture
Configuration Features : 1 X 8 Gb
Ram Supported : 3 Tb Load-reduced – Advanced Ecc 768 Gb Registered – Advanced Ecc
Storage Controllers:
Type : 1 X Raid
Controller Interface Type : Sata 6gb/s
Storage Controller Name : HPE Smart Array S100i
Channel Qty : 14
Raid Level : Raid 0, Raid 1, Raid 5, Raid 10
Graphics Controller :
Graphics Processor : Matrox G200
Video Memory : 16 Mb
Video Interfaces : Vga
Network & Communication:
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller : Hp 369i
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Lights-out Standard
Features : Wake On Lan (wol), Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab
Expansion / Connectivity :
Bays :
1 (total) / 1 (free) X External 5.25 Slim Line
4 (total) / 4 (free) X 3.5 Lff
Slots :
4 (total) / 4 (free) X Pcie 3.0 X8 – Full-length, Full-height (x4 Mode)
3 (total) / 3 (free) X Pcie 3.0 X16 – Full-length, Full-height
1 (total) / 1 (free) X Pcie 2.0 X8 – Half-length, Full-height (x4 Mode)
1 (total) / 1 (free) X Pcie 3.0 X16 – Full-length, Full-height (x8 Mode)
1 (total) / 1 (free) X Microsd Card (internal)
Interfaces :
1 X Vga
1 X Serial
4 X Lan (gigabit Ethernet)
1 X Hp Ilo
5 X Usb 3.0 (2 Front, 2 Rear, 1 Internal)
1 X Usb 2.0 (1 Internal)
Miscellaneous :
Theft/intrusion Protection :
Security Lock Slot (cable Lock Sold Separately)
Security Slot Type :
Kensington Security Slot
Compliant Standards :
Ashrae Class A4, Ashrae Class A3, Acpi 6.1
Power Description :
Device Type : Power Supply – Hot-plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (with Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Nominal Voltage : Ac 120/230 V (50/60 Hz)
Power Provided : 500 Watt
80 Plus Certification : 80 Plus Platinum
Dimensions & Weight :
Width : 6.9 In
Depth : 25.5 In
Height : 18.2 In
Weight : 46.3 Lbs
Condition : Refurbished
Availability : In Stock
Our Warranty : 90 Days
