General Information :
Manufacturer : Hewlett Packard Enterprise
Manufacturer Part Number : P03706-S01
Manufacturer Website Address : WWW.HPE.COM
Product Name: Proliant Ml30 Gen10 – 4u Tower Server ( Performance Model)
Processor & Chipset :
Cpu : Intel Xeon E3-1230v6 / 3.5 Ghz
Max Turbo Speed : 3.9 Ghz
Number Of Cores : Quad-core
Cpu Qty : 1
Max Cpu Qty : 1
Cpu Upgradability : Upgradable
Processor Main Features : Intel Turbo Boost Technology 2
Chipset Type : Intel C236
Cache Memory :
Installed Size : L3 Cache – 8 Mb
Cache Per Processor : 8 Mb
Memory :
Installed Size : 8 Gb / 64 Gb (max)
Technology : Ddr4 Sdram – Ecc
Effective Memory Speed : 2400 Mhz
Rated Memory Speed : 2400 Mhz
Memory Specification Compliance : Pc4-19200
Form Factor : Dimm 288-pin
Slots : 4 (total) / 3 (empty)
Features : Unbuffered, Dual Channel Memory Architecture
Configuration Features : 1 X 8 Gb
Ram Supported : 64 Gb Unbuffered
Storage Controllers:
Type : 1 X Raid – Pcie X4
Controller Interface Type : Sata 6gb/s
Storage Controller Name : Hp Dynamic Smart Array B140i
Channel Qty : 10
Raid Level : Raid 0, Raid 1, Raid 5, Raid 10
Optical Storage :
Type : Dvd-writer – Sata
Graphics Controller :
Graphics Processor : Matrox G200
Video Interfaces : Vga
Network & Communication:
Nterface (bus) Type : Pci Express X2
Ethernet Ports : 2 X Gigabit Ethernet
Ethernet Controller : Broadcom Bcm5720
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Lights-out 4
Features : Wake On Lan (wol), Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab
Expansion / Connectivity :
Bays :
1 (total) / 0 (free) X External 5.25
4 (total) / 4 (free) X Hot-swap 3.5 Lff
Slots :
1 (total) / 1 (free) X Pcie 3.0 X16 – Full-length, Full-height
2 (total) / 2 (free) X Pcie 3.0 X4 – Full-length, Full-height (x1 Mode)
1 (total) / 1 (free) X Pcie 3.0 X8 – Half-length, Full-height (x4 Mode)
1 Microsd Card (internal)
Interfaces :
1 X Vga (1 Rear)
2 X Lan (gigabit Ethernet)
1 X Lan (gigabit Ethernet) / Hp Ilo
6 X Usb 3.0 (4 Front, 2 Rear)
4 X Usb 2.0 (2 Rear, 2 Internal)
Miscellaneous :
Compliant Standards :
Acpi 2.0b, Fcc Class B Certified, En 61000-3-2, En55022, Ices-003, En 61000-3-3, En55024, Cispr 22, Fcc Cfr47 Part 15, Iec 60950-1, En 60950-1, Gb 9254, Cns 13438, K22, K24
Power Description :
Device Type : Power Supply
Installed Qty : 1
Nominal Voltage : Ac 120/230 V (50/60 Hz)
Power Provided : 460 Watt
80 Plus Certification : 80 Plus Gold
Efficiency : 92%
Dimensions & Weight :
Width : 6.9 In
Depth : 18.7 In
Height : 14.5 In
Weight : 29.89 Lbs
Condition : Refurbished
Availability : In Stock
Our Warranty : 90 Days
