HPE P44114-B21 DL20 Gen10+ E-2314 1P 16G 4sff Server

General Information :

Manufacturer : Hewlett Packard Enterprise

Manufacturer Part Number : P44114-B21

Manufacturer Website Address : WWW.HPE.COM

Server Scalability : 1-way

Height (rack Units) : 1u

Product Name : Dl20 Gen10+ E-2314 1p 16g 4sff Svr ( Performance Model)

Processor & Chipset :

Cpu : Intel Xeon E-2314

Clock Speed : 2.8 Ghz

Max Turbo Speed : 4.5 Ghz

Number Of Cores : Quad-core

Cpu Qty : 1

Max Cpu Qty : 1

Cpu Upgradability : Upgradable

Processor Main Features : Intel Turbo Boost Technology 2

Chipset Type : Intel C256

Cache Memory :

Installed Size : L3 Cache – 8 Mb

Cache Per Processor : 8 Mb

Memory :

Installed Size : 16 Gb / 128 Gb (max)

Technology : Ddr4 Sdram – Ecc

Effective Memory Speed : 3200 Mhz

Rated Memory Speed : 3200 Mhz

Form Factor : Dimm 288-pin

Slots : 4 (total) / 3 (empty)

Features : Unbuffered

Configuration Features : 1 X 16 Gb

Hard Drive :

Type : No Hdd

Storage Controllers:

Type : 1 X Raid

Controller Interface Type : Sata 6gb/s

Channel Qty : 6

Raid Level : Raid 0, Raid 1, Raid 5, Raid 10

Graphics Controller :

Graphics Processor : Matrox G200

Video Interfaces : Vga

Network & Communication:

Ethernet Ports : 2 X Gigabit Ethernet

Ethernet Controller : Broadcom Bcm5720

Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet

Remote Management Protocol : Snmp 3, Ipmi 2.0, Smash Clp

Remote Management Controller : Integrated Lights-out 5

Features : Wake On Lan (wol), Pxe Support

Expansion / Connectivity :

Bays :

4 (total) / 4 (free) X Hot-swap 2.5 Sff

Slots :

1 (total) / 1 (free) X Pcie 4.0 X16 – Half-length, Full-height (x8 Mode)

1 (total) / 1 (free) X Pcie 4.0 X8 (low-profile)

Interfaces :

1 X Vga

2 X Lan (gigabit Ethernet)

1 X HPE Ilo

4 X Usb 3.2 Gen 1 (1 Front, 2 Rear, 1 Internal)

1 X Usb (service Port)

Miscellaneous :

Included Accessories : HPE Short Friction Rail Kit, 3 Non-hot Plug Non-redundant Fans, Lff Drive Blanking Panel

Compliant Standards : Emc, Tls V1.2, Ashrae Class A4, Ashrae Class A3, Weee 2002/95/ec, Uefi, Acpi 6.3

Power Description :

Device Type : Power Supply

Installed Qty : 1

Voltage Required : Ac 100-120/200-240 V (50/60 Hz)

Power Provided : 500 Watt

80 Plus Certification : 80 Plus Platinum

Efficiency : 94%

Dimensions & Weight :

Width : 17.1 In

Depth : 15 In

Height : 1.7 In

Weight : 22.05 Lbs

Condition : Refurbished

Availability : In Stock

Our Warranty : 90 Days
