HPE S0E91A Aruba 6300m 48p Sr10 1g/2.5g/5g/10g Ptp/avb Class8 Poe And 4p 100g Macsec Switch
Key Features :
Network Device Type: Switch
Model: Cx 6300m
Form Factor: 1u
Connectivity Technology: Wired
Data Transfer Rate: 100 Gbps
Networking / Ports Qty:56
Data Link Protocol:gigabit Ethernet
Processor / Type: Arm Cortex A72
Ram / Total Installed Size: 8 Gb
Flash Memory / Installed Size: 32 Gb
Networking Compliant Standards:802.1p, 802.1q, 802.1s
Media Layer Supported: Layer 2, Layer 3
Power / Device Type: Power Supply
Power / Installed Qty: 2
Uplink Port: 4
Network :
Power Over Ethernet (poe) Support: Yes
Poe Power Consumption: 2640w
Mac Address Table Size: 32768
Jumbo Frame Support: 9198 Bytes
Remote Management Protocol: Ipv6, Ipv4, Snmp
Routing Protocol: Ripv2, Ospf, Static Ip
Encryption Algorithm: Macsec
Authentication Method: Radius, Md5, Tacacs+
Interfaces / Ports :
Interfaces: 100m/1g/2.5g/5g/10g Baset Class 8 Poe,10g/25g/40g/100g Qsfp/qsfp28,usb-c Console,rj45 Console,oobm,usb Type A Host
Power :
Power Source : Ac Power Supply
Frequency: 60 Hz,50 Hz
Number Of Power Supplies Supported : 2
Poe (rj-45) Port : Yes
Redundant Power Supply Supported : Yes
Poe Budget: 2640 W
Dimensions & Weight
Weight:11.60 Lb
Width :17.4 Inch
Depth : 18.6 Inch
Height: 1.73 Inch
Condition : New Retail Factory Sealed.
Availability : In Stock.
Our Warranty : 90 Days.
