Seagate 37GB Int 3.5-in 40-pin SCA Fibre Channel 15K rpm 8MB 5-Yr Warr Bulk

The Cheetah 15K.4 is the best performance, lowest cost of ownership, 3.5-inch disc drive. It enables higher performance with fewer drives, while offering the industry’s highest reliability.

ST336754FC Specifications

Technical Information

•
  Storage Capacity:

  36.70 GB

Drive Performance

•
  Maximum External Data Transfer Rate:

  200 MBps (1.6 Gbps)
•
  Maximum Internal Data Transfer Rate:

  142.8 MBps (1.1 Gbps)
•
  Rotational Speed:

  15000 rpm
•
  Buffer:

  8 MB
•
  Average Seek Time:

  4 ms
•
  Average Latency:

  2 ms

Interfaces/Ports

•
  Drive Interface:

  Fibre Channel

Power Description

•
  Input Voltage:

  12 V DC

Physical Characteristics

•
  Drive Type:

  Internal
•
  Drive Width:

  3.5″
•
  Height:

  1.0″
•
  Width:

  0.5″
•
  Depth:

  5.8″
•
  Weight (Approximate):

  1.50 lb

Miscellaneous

•
  Additional Information:

• Spinup Time: 20 sec
• Track Density (TPI): 85000 tracks/inch
• Recording Density (BPI): 628000 bits/inch Maximum
• Bytes/Track: 471916 Average
• Enhanced Error Correction Code
• Fluid Dynamic Bearing Motor
• Full Duty Cycle Reliability
• 30% more IOPS and more than 20% faster response times than 3.5-inch 10K drives

•
  Transfer Rate:


• Formatted Internal Transfer Rate: 85 – 142 MBytes/sec
•
  Certifications & Standards:

• S.M.A.R.T

Warranty

•
  Limited Warranty:

  5 Year
