Toshiba HDD1524 40GB 4200RPM 1.8″ MicroDrive.

Toshiba introduces a 40GB 1.8-inch embedded HDD, the MK4004GAH. Enabling some of today’s most exciting, small form factor mobile devices, the new mini-drive offers manufacturers significant storage for consumer, commercial and PC applications – such as music players, handheld PCs, PDAs, wearable computers and laptops.

HDD1524 Specifications

Technical Information

•
  Storage Capacity:

  40 GB

Drive Performance

•
  Maximum External Data Transfer Rate:

  100 MBps (800 Mbps)
•
  Maximum Internal Data Transfer Rate:

  31.6 MBps (253.1 Mbps)
•
  Rotational Speed:

  4200 rpm
•
  Buffer:

  512 KB
•
  Average Latency:

  7.14 ms

Interfaces/Ports

•
  Drive Interface:

  IDE Ultra ATA/100 (ATA-6)

Power Description

•
  Input Voltage:

  3.3 V DC

Physical Characteristics

•
  Drive Type:

  Internal
•
  Drive Width:

  1.8″
•
  Height:

  0.3″
•
  Width:

  2.1″
•
  Depth:

  3.1″
•
  Weight (Approximate):

  2.19 oz

Miscellaneous

•
  Additional Information:

• User Data Cylinders: 38160
• Logical Blocks (LBA): 78126048
• Track Density (TPI): 3465 (88k)
• Product Life: 5 years or 20000 power ON hours
• Spin-up Time: 3.5sec (Typical)
•
  Compatibility:

• PC
•
  Certifications & Standards:

• UL 1950
• CSA22.2 No.950
• EN 60950
• BSMI

Warranty

•
  Limited Warranty:

  1 Year
