CISCO WS-C3560X-24U-E Catalyst 3560x-24u-e Switch L3 Managed 24 X 10/100/1000 (upoe) Rack-mountable Upoe.
key Features :
Device Type : Switch – 24 Ports – L3 – Managed
Enclosure Type : Rack-mountable 1u
Interfaces : Gigabit Ethernet
Ports : 24 X 10/100/1000 (upoe)
Power Over Ethernet (poe) : Upoe
Poe Budget : 800 W
Performance :
Switching Fabric Bandwidth : 160 Gbps
Forwarding Performance : 65.5 Mpps
Capacity :
Virtual Interfaces (vlans) : 1005
Switched Virtual Interfaces (svis) : 1000
Jumbo Frame Support : 9216
Routing Protocol : Ospf, Bgp-4, Is-is, Rip-1, Rip-2, Eigrp, Hsrp, Pim-sm, Pim-dm, Eigrp For Ipv6, Ospfv3, Pim-ssm, Static Ipv4 Routing, Static Ipv6 Routing, Policy-based Routing (pbr), Ripng
Remote Management Protocol : Snmp 1, Snmp 2, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Snmp 2c, Tftp, Ssh, Cli
Features : Hot Swap Module Replacement, Layer 2 Switching, Dynamic Ip Address Assignment , Dhcp Support, Auto-negotiation, Arp Support, Trunking, Vlan Support, Auto-uplink (auto Mdi/mdi-x), Igmp Snooping, Syslog Support, Traffic Shaping, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (rstp) Support, Dhcp Snooping, Dynamic Trunking Protocol (dtp) Support, Port Aggregation Protocol (pagp) Support, Trivial File Transfer Protocol (tftp) Support, Access Control List (acl) Support, Quality Of Service (qos), Jumbo Frames Support, Virtual Route Forwarding-lite (vrf-lite), Mld Snooping, Dynamic Arp Inspection (dai), Per-vlan Spanning Tree Plus (pvst+), Eigrp Stub Routing, Uni-directional Link Detection (udld), Shaped Round Robin (srr), Link Aggregation Control Protocol (lacp), Remote Switch Port Analyzer (rspan)
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.1s, Ieee 802.1ae
Power : Ac 120/230 V (50/60 Hz)
Power Redundancy : Optional
Condition: Refurbished.
Availability: Call.
Our Warranty: 90 Days.
